FUNCTION(S)

• Remove the outer sheath
• Remove the outer semi-conductor
• Remove the insulation
• Shape the insulation

DIAMETER

• ø16 - 58 mm
• ø0.630 - 2.283 in

TO DO WHAT

• The MF3/60-SR tools enables the user to :
• Remove the outer sheath (PE-PVC-PR) with a straight and neat cut
• Score the peelable semiconductor (with the SR scoring stylus delivered with the tool)
• Set the length to be removed and remove thicker insulation with a straight and neat cut

PRODUCT BENEFITS

• Tuning of the pitch of the tool
• Embeded wear pads to protect the tool from the contact with the outer sheath
• For thick insulation

PELABLE SEMICON THICKNESS CAPACITY

• 0.4 - 1.5 mm

INSULATION THICKNESS CAPACITY

• 11 mm

STYLUS INCLUDED

• SR

CERTIFICATIONS

• Approved by ENEDIS
